Cast Iron Peripheral Water Pump

Inquire Add to Basket

Model:PM16
YINJIA Pump is a professional surface clean water pump manufacturer in China since 1990, has specialized in manufacturing various of surface clean water pumps, as well as providing quality cast iron peripheral water pump for the world. We are committed to providing high quality product at a competitive price and backed up with superior service. Welcome to inquiry for cast iron peripheral water pump.

China Suppliers Factory Made in China Manufacturers Wholesale Price Price list Cast Iron Peripheral Water Pump

Product Description

YINJIA as the professional manufacturer, we would like to provide you high quality cast Iron peripheral water pump. And we will offer you the best after-sale service and timely delivery. The PM16 cast iron peripheral water pump belongs to the single-phase peripheral pump category. Its power of only 0.37 kW makes it one of the most used items for applications where high flow rates and heads are not required but this also has the advantage of having an item with small dimensions and very low energy consumption.

Product Feature And Application

APPLICATIONS
-Suitable for use with clean water, or non-aggressive liquids only, without sand or other solid impurities.
-Suitable for small living water supply, automatic water sprinkler system, small air conditioner system or supporting equipment etc.
DESIGN FEATURES
-Pump body/motor bracket: cast iron
-Impeller: Brass
-100% copper winding
-Built-in thermal protector for single phase motor
-Motor shaft: AISI 304 welded shaft
-Mechanical seal: Graphite/Ceramic/NBR/S.S304
SPECIAL FEATURES ON REQUEST
-Anti-rust treatment for casting
-No block system
-AISI 1045 motor shaft
-Carbon/SiC/V mechanical seal
-Other voltage and frequnecy
-Insultation class: F
OPERATING LIMITS
-Total suction lift up to 6-8 mt. with foot valve
-Max. operating pressure: 8 bar.
-Max. ambient temperature: +40℃
-Max. liquid temperature: +90℃
-Max. altitude: +1000 mt.
MOTOR
-Insultation class: B
-Protection: Ip44
-Speed of rotation: 2850rpm
-Continuous duty: S1

Product Parameter (Specification)

PERFORMANCE

PM16 - 0.37 kW / 0.5 HP - Max. Head 40m - Max. Flow 35 l/min - 1" water pump

DIMENSIONS

PM16 EXPLODING DRAWING
