AC JET Cleaning Self-priming Pump

Model:JETN
YINJIA Pump is a professional surface clean water pump manufacturer in China since 1990, has specialized in manufacturing various of surface clean water pumps, as well as providing quality AC JET cleaning self-priming pump for the world. We are committed to providing high quality product at a competitive price and backed up with superior service. Welcome to inquiry for AC JET cleaning self-priming pump.

Send Inquiry PDF DownLoad

Product Description

YINJIA is AC JET cleaning self-priming pump manufacturers and suppliers in China who can wholesale AC JET cleaning self-priming pump. JET/N series AC JET ceaning self-priming pump belongs to the single-phase self-priming JET pump category. The electrical JET pumps have high performance in terms of head and flow rate, ideal for residential use when there is a need for the self- priming function, suitable to drain water from river and shallow well. Pumps should be installed in a covered area, protected against the weather.

Product Feature And Application

APPLICATIONS
-Suitable for use with clean water, or non-aggressive liquids only, without sand or other solid impurities.
-Suitable for small living water supply, automatic water sprinkler system, small air conditioner system or supporting equipment etc.
DESIGN FEATURES
-Pump body/motor bracket: cast iron
-Impeller: Brass
-Ejection union: PPO
-100% copper winding
-Built-in thermal protector for single phase motor
-Motor shaft: AISI 304 welded shaft
-Mechanical seal: Graphite/Ceramic/NBR/S.S304
SPECIAL FEATURES ON REQUEST
-Anti-rust treatment for casting
-PPO/SUS304 impeller
-Cast iron diffuser, brass nozzle
-AISI 1045 motor shaft
-Carbon/SiC/V mechanical seal
-Other voltage and frequnecy
-Insultation class: F
OPERATING LIMITS
-Total suction lift up to 9 mt. with foot valve
-Max. operating pressure: 8 bar.
-Max. ambient temperature: +40℃
-Max. liquid temperature: +60℃
-Max. altitude: +1000 mt.
MOTOR
-Insultation class: B
-Protection: IP44
-Speed of rotation: 2850rpm
-Continuous duty: S1

Product Parameter (Specification)

PERFORMANCE

JET50N - 0.37 kW / 0.5 HP - Max. Head 42m - Max. Flow 40 l/min - 1" water pump
JET75N - 0.55 kW / 0.75 HP - Max. Head 46m - Max. Flow 45 l/min - 1" water pump
JET100N - 0.75 kW / 1 HP - Max. Head 50m - Max. Flow 50 l/min - 1" water pump
JET150N - 1.1 kW / 1.5 HP - Max. Head 53m - Max. Flow 100 l/min - 1.25"*1" water pump
JET200N - 1.5 kW / 2 HP - Max. Head 60m - Max. Flow 110 l/min - 1.25"*1" water pump

DIMENSIONS
