You are welcomed to come to YINJIA factory to buy the latest selling, low price, and high-quality automatic booster systems pump. We look forward to cooperating with you. The automatic booster systems pump consist of a peripheral pump or JET pump or centrifugal pump. A water pump, a pressure tank, an airtight pressure switch, a pressure gauge and a connecting flexible pipe, make the pump automatic more convenient to use. The pressure tank, equipped with a non-toxic rubber membrane, has been pre-filled with air pressure of approx 0.12 MPa before leaving the factory.These systems give suitable mains water pressure as required by modern domestic applications and industrial applications, and will ensure enough water to supply all user outlets.Most of the pumps included in our range of products can actually be used to form automatic booster systems.
APPLICATIONS
-Suitable for use with clean water, or non-aggressive liquids only, without sand or other solid impurities.
-Suitable for small living water supply, automatic water sprinkler system, small air conditioner system or supporting equipment etc.
DESIGN FEATURES
-Pump body/motor bracket: cast iron
-Impeller: Brass
-Bearing: C&U
-100% copper winding
-Built-in thermal protector for single phase motor
-Motor shaft: AlSI 304 welded shaft
-Mechanical seal: Carbon/Ceramic/NBR/SUS304
ACCESSORY
-Tank: 19L/24L/50L Carbon Steel Pressure Tank (Stainless steel tank optional)
-Flexible hose: 1"/1"
-Pressure Switch: ON: 1.4 Bar, OFF: 2.8 Bar
-Pressure Gauge: 6 Bar (100PSI)
-Brass Connector: 5 way (3 way, 4 way optional)
-Cable: 1.0 meter (On Request)
OPERATING LIMITS
-Total suction lift up to 6-8 mt. with foot valve
-Max. operating pressure: 8 bar.
-Max. ambient temperature: +40℃
-Max. liquid temperature: +90℃
-Max. altitude: +1000 mt.
MOTOR
-Insultation class: B
-Protection: IP44
-Speed of rotation: 2850rpm
-Continuous duty: S1
AUTOIDB EXPLODING DRAWING
