Centrifugal Pump DK Series

Name: Centrifugal Pump DK Series
Brand: Yinjia
Rating: 5.0 (47 reviews)


Availability:

Inquire Add to Basket

Model:
DK Series
Brand:
Yinjia

YINJIA Centrifugal Pump DK Series is designed for irrigation, open water transfer and farm pressure supply. Key features include DK high-flow hydraulics, clean-water transfer capacity and service-friendly casing design, supporting clean-water flow, pressure stability and reseller-friendly model selection. Suitable for farm pump distributors and irrigation equipment buyers. Contact YINJIA for large-flow model selection and bulk purchasing.

Centrifugal Water Pump Water Pump Motor Pump Centrifugal pump Water Pumps Garden Water Pump Pressure Pump Electric Motor Pump Circulation Pump

Product Description

YINJIA is a professional leader China centrifugal pump for water system manufacturer with high quality and reasonable price. Welcome to contact us. DK series centrifugal pump for water system belongs to the electrical centrifugal pump category, is a classical and popular pump in the global market, like open type impeller for Sri Lanka is available. Single phase and three phase are available. Single impeller centrifugal pumps suitable to cover any small, medium or large capacity request, for domestic, agricultural and industrial purposes. Pumps should be installed in a covered area, protected against the weather.

Product Feature And Application

APPLICATIONS
-Suitable for use with clean water, or non-aggressive liquids only, without sand or other solid impurities.
-Suitable for industrial use and urban water supply,pressure boosting for high buildings and fire fighting,garden imgation,long-distance water transfer,heating ventilation and air controlling, circulation andpressure boosting for cold hot water, and supporting equipment etc.
DESIGN FEATURES
-Pump body/motor bracket: cast iron
-Impeller: Brass
-100% copper winding
-Built-in thermal protector for single phase motor
-Motor shaft: AISI 304 welded shaft
-Mechanical seal: Graphite/Ceramic/NBR/S.S304
SPECIAL FEATURES ON REQUEST
-Anti-rust treatment for casting
-AISI 1045 motor shaft
-Carbon/SiC/V mechanical seal
-Other voltage and frequnecy
-Insultation class: F
OPERATING LIMITS
-Total suction lift up to 6-8 mt. with foot valve
-Max. operating pressure: 8 bar.
-Max. ambient temperature: +40℃
-Max. liquid temperature: +90℃
-Max. altitude: +1000 mt.
MOTOR
-Insultation class: B
-Protection: IP44
-Speed of rotation: 2850rpm
-Continuous duty: S1
